CK Worldwide CK1312H RG TIG Torch, 130 Amp, Gas-Cooled, Rigid Head, 12.5

The CK1312H delivers precision TIG welding performance with 130-amp capacity and gas-cooled operation, engineered for production environments requiring consistent arc control and extended run times.

This rigid head TIG torch combines reliable gas cooling with robust construction for demanding fabrication work. The fixed head geometry ensures repeatable electrode positioning, reducing arc wander and improving weld consistency on critical joints. Gas cooling eliminates the complexity of water systems while providing adequate heat dissipation for continuous operation.

• 130 Amp @ 100% duty cycle — continuous operation rating for production welding
• Gas-cooled design — no water circulation required, simplified setup and maintenance
• Rigid head construction — fixed geometry for stable arc positioning and consistent results
• 12.5' cable length — standard reach for most welding applications
• 3-piece cable assembly — separate power, gas, and ground connections

Compatible Consumables

• 300S — Short Backcap
• 300L — Long Backcap
• 3C116 — 1/16" (1.6mm) Collet
• 3C332 — 3/32" (2.4mm) Collet
• 3C418 — 1/8" (3.2mm) Collet
• 3CB116 — 1/16" (1.6mm) Collet Body
• 3CB332 — 3/32" (2.4mm) Collet Body
• 3CB418 — 1/8" (3.2mm) Collet Body
• 3A5 — #5 (5/16" 8.0mm) Alumina Cup
• 3A6 — #6 (3/8" 9.6mm) Alumina Cup

Compatible with standard 3-series consumables and accessories. Ideal for steel, stainless steel, and aluminum welding applications where consistent arc geometry and reliable performance are essential.
