CK Worldwide CK26P-25-R 200 Amp Gas-Cooled TIG Torch, Rigid Pencil Head, 25

The CK26P-25-R delivers precision TIG welding performance in a lightweight, pencil-style rigid head design. This 200-amp gas-cooled torch operates at 100% duty cycle with both AC high frequency and DC straight polarity, making it ideal for demanding fabrication work where maneuverability and control are critical.

• 200 amp rating at 100% duty cycle (ACHF or DCSP)
• Pencil rigid head style for precise welding control
• Gas-cooled design for maximum heat dissipation
• 25-foot standard cable length for extended reach
• Single-piece cable configuration reduces connection points
• Lightweight construction at 3 oz (85g) for reduced operator fatigue
• 9-1/4" overall length (23.5cm) for excellent balance
• 7/8" x 14RH power cable connections for secure attachment
• No valve design for streamlined operation
• Compatible with 3 Series head accessories

Compatible Consumables

• 300S — Short Backcap
• 300L — Long Backcap
• 3C116 — 1/16" Collet
• 3C332 — 3/32" Collet
• 3CB116 — 1/16" Collet Body
• 3CB332 — 3/32" Collet Body
• 3A5 — #5 Alumina Cup
• 3A6 — #6 Alumina Cup
• T1167GC2 — 1/16" x 7" Ceriated Tungsten
• T3327GC2 — 3/32" x 7" Ceriated Tungsten

This pencil-style torch excels in applications requiring precise arc placement and excellent visibility, particularly for intricate welding on thin materials, tube work, and detail fabrication. The rigid head design eliminates flex for consistent arc positioning, while the gas-cooled system ensures reliable performance in continuous-duty applications.
