CK Worldwide CKM2312SF - 300 Amp Water-Cooled TIG Torch, Rigid Head, 12.5' Super-Flex Cable

The CKM2312SF delivers 300 amp capacity at 100% duty cycle for demanding TIG applications, featuring a rigid head design for precise arc control and superflex cables that provide maximum flexibility without compromising durability.

This water-cooled torch incorporates CK's Max Flow technology to maintain optimal operating temperatures during extended welding sessions. The 12.5-foot superflex cable construction offers superior maneuverability around complex workpieces while the 1-3/8" O.D. barrel design ensures compatibility with standard 2 Series accessories. At just 6 oz (170gm), this torch reduces operator fatigue during long welding sessions.

• Amperage Rating: 300 amp @ 100% duty cycle
• Cooling Type: Water-cooled with Max Flow technology
• Head Style: Rigid for precise arc control
• Cable Length: 12.5 feet (3.8m)
• Cable Type: Superflex for enhanced flexibility
• Weight: 6 oz (170gm)
• Barrel Diameter: 1-3/8" (35mm) O.D.
• Thread Pattern: 5/16" x 24 (2 Series)

Compatible Consumables

• 200L — Long Backcap
• 200M — Medium Backcap
• 200S — Short Backcap
• 2C116 — 1/16" Collet
• 2C332 — 3/32" Collet
• 2CB116 — 1/16" Collet Body
• 2CB332 — 3/32" Collet Body
• 2A5 — #5 Alumina Cup
• 2A6 — #6 Alumina Cup
• 2AG5 — #5 Gas Lens Cup

The CKM2312SF torch head accepts standard 2 Series consumables and is designed for professional fabrication shops requiring consistent performance on stainless steel, aluminum, and exotic alloys. Compatible with most water-cooled TIG welding systems equipped with standard CK-style connections.
