CK Worldwide CKM3525 - 400 Amp Water-Cooled TIG Torch, Rigid Head, 25' Cable

The CK Worldwide CKM3525 delivers professional-grade performance with 400 amp capacity at 100% duty cycle, engineered for demanding production welding environments. This water-cooled rigid head torch features Max Flow cooling technology and 25-foot standard cables for extended reach applications.

Built on CK's proven 3-series platform, this torch combines precision control with exceptional durability for critical welding applications. The rigid head design eliminates flex and movement, ensuring consistent arc placement and superior weld quality on heavy fabrication work.

• 400 amp rating at 100% duty cycle
• Water-cooled with Max Flow technology
• Rigid head style for maximum stability
• 25-foot standard cables for extended reach
• 15-inch torch body with 1-3/8" O.D. barrel
• 6.25 oz total weight for balanced handling
• 3-series consumable system for versatile applications
• 3-piece cable configuration with standard flexibility

Compatible Consumables

• 3A4 — #4 Alumina Cup
• 3A5 — #5 Alumina Cup
• 3A6 — #6 Alumina Cup
• 3C116 — 1/16" Collet
• 3C332 — 3/32" Collet
• 3C418 — 1/8" Collet
• 3CB116 — 1/16" Collet Body
• 3CB332 — 3/32" Collet Body
• 3CB418 — 1/8" Collet Body
• 300L — Long Back Cap

Ideal for high-amperage aluminum, stainless steel, and exotic alloy welding where precision and consistent performance are critical. Compatible with standard 3-series consumables and AWS-certified tungsten electrodes from .040" through 1/8" diameter.
