Nic-L-Weld™ 59 Nickel Alloy Stick (SMAW) Electrode

Nic-L-Weld™ 59 is a general purpose, nickel-iron alloy electrode for production, salvage and repair of all cast iron. It is suited for joining, filling and build-up of gray and cast irons. It can be used for fabrication and repair of pump housings, valves, castings, cast and malleable fittings, Deposits are machinable and have high strength.

• Nic-L-Weld™ 59 nickel alloy stick (SMAW) electrode POP 1/8 x 14 in. x 4 ea. tube/box
• Nic-L-Weld™ 59 is a general purpose, nickel-iron alloy electrode for production, salvage and repair of all cast iron. It is suited for joining, filling and build-up of gray and cast irons. It can be used for fabrication and repair of pump housings, valves, castings, cast and malleable fittings, Deposits are machinable and have high strength.
• General purpose nickel-iron electrode for cast irons
• Good machinability
• Close color match to cast iron
• 70,000 psi maximum tensile strength (as welded)
• pre-heat heavy castings to approximately 400 degrees F (204 degrees C) for best results
• AC or DC reverse polarity
• Used for production, salvage and repair of cast irons
• Conforms to AWS A5.15, ENiFeCl
• Nic-L-Weld™ 59 nickel alloy electrode 1/8 x 14 in. x 4 ea. tube/box POP
• 1 Year
• Nic-L-Weld™ 59
• Harris
• StickSMAW

• Alloy Type: CastIron
• Chemical Composition: Carbon 2.0%;Manganese 2.5%;Silicon 4.0%;Sulfur 0.03%;Nickel 45-60% min.;Copper 2.5%;Aluminum 1.0%;Sulfur 0.03%;Iron Remainder%
• Classification: AWS A5.15, ENiFeCl
• Color: Silver-gray color is a good match to cast iron
• Diameter: 1/8 in (3.2 mm)
• Elongation: 18% min. (mechanical properties as welded)
• Material: Nickel Iron
• NSF Compliant: No
• RoHS Compliant: No
• Size: 4 ea. tube
• Special Instructions: Good machinability
• Tensile Strength (PSI): Up to 70,000 (mechanical properties as welded)
• Typical Application: Joining, filling and building-up gray and alloyed cast irons;Fabrication;Repair pump housings;Valves;Castings;Cast;Maleable fittings;General repair of all cast irons.
• Yield Strength (PSI): Up to 80,000 (mechanical properties as welded)

What's Included: Nic-L-Weld™ 59 nickel alloy electrode 1/8 x 14 in. x 4 ea. tube/box POP

Model Name: Nic-L-Weld™ 59
